| Part Number | T322F476M035AT | T322F476K035AT | T322F476M035AS |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 47 µF | 47 µF | 47 µF |
| Tolerance | ±20% | ±10% | ±20% |
| Voltage - Rated | 35 V | 35 V | 35 V |
| Type | Molded | Molded | Molded |
| ESR (Equivalent Series Resistance) | 800mOhm @ 100kHz | 800mOhm | 800mOhm @ 100kHz |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial |
| Size / Dimension | 0.300" Dia x 0.710" L (7.62mm x 18.03mm) | 0.300" Dia x 0.710" L (7.62mm x 18.03mm) | 0.300" Dia x 0.300" L (7.62mm x 7.62mm) |
| Height - Seated (Max) | - | - | - |
| Lead Spacing | - | - | - |
| Manufacturer Size Code | F | F | F |
| Ratings | - | - | - |
| Features | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - |
