| Part Number | T322E686K010AT | T322E686K015AT | T322E686K020AT | T322E686K010AS |
|---|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active | Active |
| Capacitance | 68 µF | 68 µF | 68 µF | 68 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% |
| Voltage - Rated | 10 V | 15 V | 20 V | 10 V |
| Type | Molded | Molded | Molded | Molded |
| ESR (Equivalent Series Resistance) | 1.3Ohm | 1Ohm | 900mOhm | 1.3Ohm |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.280" Dia x 0.530" L (7.11mm x 13.46mm) | 0.280" Dia x 0.530" L (7.11mm x 13.46mm) | 0.280" Dia x 0.530" L (7.11mm x 13.46mm) | 0.280" Dia x 0.530" L (7.11mm x 13.46mm) |
| Height - Seated (Max) | - | - | - | - |
| Lead Spacing | - | - | - | - |
| Manufacturer Size Code | E | E | E | E |
| Ratings | - | - | - | - |
| Features | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - |
