Please send RFQ , we will respond immediately.
| Part Number | T322C106J020AS | T322C106J020AT | T322C106M020AS | T322C106K020AS |
|---|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active | Active |
| Capacitance | 10 µF | 10 µF | 10 µF | 10 µF |
| Tolerance | ±5% | ±5% | ±20% | ±10% |
| Voltage - Rated | 20 V | 20 V | 20 V | 20 V |
| Type | Molded | Molded | Molded | Molded |
| ESR (Equivalent Series Resistance) | 2.9Ohm @ 100kHz | 2.9Ohm | 2.9Ohm @ 100kHz | 2.9Ohm |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.180" Dia x 0.180" L (4.57mm x 4.57mm) | 0.180" Dia x 0.345" L (4.57mm x 8.76mm) | 0.180" Dia x 0.345" L (4.57mm x 8.76mm) | 0.180" Dia x 0.345" L (4.57mm x 8.76mm) |
| Height - Seated (Max) | - | - | - | - |
| Lead Spacing | - | - | - | - |
| Manufacturer Size Code | C | C | C | C |
| Ratings | - | - | - | - |
| Features | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - |
