| Part Number | SMP253MA4150MTR24 | SMP253MA4250MTR24 | SMP253MA4100MTR24 |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 1500 pF | 2500 pF | 1000 pF |
| Tolerance | ±20% | ±20% | ±20% |
| Voltage Rating - AC | 250V | 250V | 250V |
| Voltage Rating - DC | 1500V (1.5kV) | 1500V (1.5kV) | 1500V (1.5kV) |
| Dielectric Material | Paper, Metallized | Paper, Metallized | Paper, Metallized |
| ESR (Equivalent Series Resistance) | - | - | - |
| Operating Temperature | -40°C ~ 100°C | -40°C ~ 100°C | -40°C ~ 100°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard SMD | Nonstandard SMD | Nonstandard SMD |
| Size / Dimension | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.500" L x 0.453" W (12.70mm x 11.50mm) |
| Height - Seated (Max) | 0.264" (6.70mm) | 0.264" (6.70mm) | 0.264" (6.70mm) |
| Termination | Solder Pads | Solder Pads | Solder Pads |
| Lead Spacing | - | - | - |
| Applications | EMI, RFI Suppression | EMI, RFI Suppression | EMI, RFI Suppression |
| Ratings | Y2 | Y2 | Y2 |
| Features | - | - | - |
