| Part Number | PME271M610KR30 | PME271M660KR30 | PME271M610MR30 |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 0.1 µF | 0.6 µF | 0.1 µF |
| Tolerance | ±10% | ±10% | ±20% |
| Voltage Rating - AC | 275V | 275V | 275V |
| Voltage Rating - DC | 630V | - | - |
| Dielectric Material | Paper, Metallized | Paper, Metallized | Paper, Metallized |
| ESR (Equivalent Series Resistance) | - | - | - |
| Operating Temperature | -40°C ~ 110°C | -40°C ~ 110°C | -40°C ~ 110°C |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial |
| Size / Dimension | 0.945" L x 0.299" W (24.00mm x 7.60mm) | 1.201" L x 0.602" W (30.50mm x 15.30mm) | 0.945" L x 0.299" W (24.00mm x 7.60mm) |
| Height - Seated (Max) | 0.551" (14.00mm) | 0.866" (22.00mm) | 0.551" (14.00mm) |
| Termination | PC Pins | PC Pins | PC Pins |
| Lead Spacing | 0.799" (20.30mm) | 1.000" (25.40mm) | 0.799" (20.30mm) |
| Applications | EMI, RFI Suppression | EMI, RFI Suppression | EMI, RFI Suppression |
| Ratings | X2 | X2 | X2 |
| Features | - | - | - |
