KEMET-PHE426KD6390JR06L2 - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	0.39 µF
Tolerance:	±5%
Voltage Rating - AC:	220V
Voltage Rating - DC:	400V
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	-
Operating Temperature:	-55°C ~ 105°C
Mounting Type:	Through Hole
Package / Case:	Radial
Size / Dimension:	1.024" L x 0.276" W (26.00mm x 7.00mm)
Height - Seated (Max):	0.650" (16.50mm)
Termination:	PC Pins
Lead Spacing:	0.886" (22.50mm)
Applications:	DC Link, DC Filtering; High Frequency, Switching; High Pulse, DV/DT
Ratings:	-
Features:	-

KEMET PHE426KD6390JR06L2
