KEMET-PEH200SV5100MU2 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	10000 µF
Tolerance:	±20%
Voltage - Rated:	250 V
ESR (Equivalent Series Resistance):	14mOhm @ 100Hz
Lifetime @ Temp.:	19000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	18 A @ 100 Hz
Ripple Current @ High Frequency:	44 A @ 10 kHz
Impedance:	-
Lead Spacing:	1.260" (32.00mm)
Size / Dimension:	3.016" Dia (76.60mm)
Height - Seated (Max):	5.748" (146.00mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	Radial, Can - Screw Terminals

KEMET PEH200SV5100MU2
