KEMET-PEH200KO6100MB2 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	100000 µF
Tolerance:	±20%
Voltage - Rated:	40 V
ESR (Equivalent Series Resistance):	8mOhm @ 100Hz
Lifetime @ Temp.:	15000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	24.9 A @ 100 Hz
Ripple Current @ High Frequency:	-
Impedance:	8 mOhms
Lead Spacing:	1.122" (28.50mm)
Size / Dimension:	2.622" Dia (66.60mm)
Height - Seated (Max):	4.213" (107.00mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	Radial, Can - Screw Terminals

KEMET PEH200KO6100MB2
