KEMET-PEH169VH3470QB2 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	470 µF
Tolerance:	-10%, +30%
Voltage - Rated:	400 V
ESR (Equivalent Series Resistance):	160mOhm @ 100Hz
Lifetime @ Temp.:	5000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	4 A @ 100 Hz
Ripple Current @ High Frequency:	13.5 A @ 10 kHz
Impedance:	-
Lead Spacing:	0.866" (22.00mm)
Size / Dimension:	2.031" Dia (51.60mm)
Height - Seated (Max):	2.933" (74.50mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	Radial, Can - Screw Terminals

KEMET PEH169VH3470QB2
