KEMET-PEG225MJ4140QE1 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	1400 µF
Tolerance:	-10%, +30%
Voltage - Rated:	63 V
ESR (Equivalent Series Resistance):	57mOhm @ 100Hz
Lifetime @ Temp.:	2000 Hrs @ 150°C
Operating Temperature:	-40°C ~ 150°C
Polarization:	Polar
Ratings:	AEC-Q200
Applications:	Automotive
Ripple Current @ Low Frequency:	-
Ripple Current @ High Frequency:	20.9 A @ 5 kHz
Impedance:	-
Lead Spacing:	-
Size / Dimension:	0.787" Dia (20.00mm)
Height - Seated (Max):	1.366" (34.70mm)
Surface Mount Land Size:	-
Mounting Type:	Through Hole
Package / Case:	Axial, Can

KEMET PEG225MJ4140QE1
