KEMET-PEG124YD1470QL1 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	4.7 µF
Tolerance:	±20%
Voltage - Rated:	450 V
ESR (Equivalent Series Resistance):	11Ohm @ 100Hz
Lifetime @ Temp.:	5000 Hrs @ 105°C
Operating Temperature:	-40°C ~ 105°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	79 mA @ 100 Hz
Ripple Current @ High Frequency:	82.16 mA @ 100 kHz
Impedance:	-
Lead Spacing:	-
Size / Dimension:	0.512" Dia (13.00mm)
Height - Seated (Max):	1.142" (29.00mm)
Surface Mount Land Size:	-
Mounting Type:	Through Hole
Package / Case:	Axial, Can

KEMET PEG124YD1470QL1
