KEMET-PEG124MC310AQT1 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	100 µF
Tolerance:	-10%, +30%
Voltage - Rated:	63 V
ESR (Equivalent Series Resistance):	730mOhm @ 100Hz
Lifetime @ Temp.:	2000 Hrs @ 125°C
Operating Temperature:	-40°C ~ 125°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	328 mA @ 100 Hz
Ripple Current @ High Frequency:	341.12 mA @ 100 kHz
Impedance:	-
Lead Spacing:	-
Size / Dimension:	0.512" Dia (13.00mm)
Height - Seated (Max):	0.787" (20.00mm)
Surface Mount Land Size:	-
Mounting Type:	Through Hole
Package / Case:	Axial, Can

KEMET PEG124MC310AQT1
