| Part Number | PEG124MB2470QL1 | PEG124MB247VQL1 |
|---|---|---|
| Manufacturer | KEMET | KEMET |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Capacitance | 47 µF | 47 µF |
| Tolerance | -10%, +30% | -10%, +30% |
| Voltage - Rated | 63 V | 63 V |
| ESR (Equivalent Series Resistance) | 1.6Ohm @ 100Hz | 1.6Ohm @ 100Hz |
| Lifetime @ Temp. | 2000 Hrs @ 125°C | 2000 Hrs @ 125°C |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Polarization | Polar | Polar |
| Ratings | - | - |
| Applications | General Purpose | General Purpose |
| Ripple Current @ Low Frequency | 190 mA @ 100 Hz | - |
| Ripple Current @ High Frequency | 197.6 mA @ 100 kHz | - |
| Impedance | - | - |
| Lead Spacing | - | - |
| Size / Dimension | 0.394" Dia (10.00mm) | 0.394" Dia x 1.142" L (10.00mm x 29.00mm) |
| Height - Seated (Max) | 1.142" (29.00mm) | - |
| Surface Mount Land Size | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial, Can | Axial, Can |
