Please send RFQ , we will respond immediately.
| Part Number | M39014/05-2261 | M39014/05-2861 | M39014/05-2061 | M39014/05-2231 |
|---|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active | Active |
| Capacitance | 10000 pF | 10000 pF | 10000 pF | 470 pF |
| Tolerance | ±10% | ±10% | ±10% | ±10% |
| Voltage - Rated | 100V | 100V | 100V | 100V |
| Temperature Coefficient | BX | BX | BX | BX |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Features | - | - | - | - |
| Ratings | - | - | - | - |
| Applications | High Reliability | High Reliability | High Reliability | High Reliability |
| Failure Rate | S (0.001%) | P (0.1%) | R (0.01%) | S (0.001%) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.090" Dia x 0.250" L (2.29mm x 6.35mm) | 0.090" Dia x 0.250" L (2.29mm x 6.35mm) | 0.090" Dia x 0.250" L (2.29mm x 6.35mm) | 0.090" Dia x 0.160" L (2.29mm x 4.06mm) |
| Height - Seated (Max) | - | - | - | - |
| Thickness (Max) | - | - | - | - |
| Lead Spacing | - | - | - | - |
| Lead Style | Straight | Straight | Straight | Straight |
