| Part Number | C4AF9BW4680T3FK | C4AF9BW4680A3FK |
|---|---|---|
| Manufacturer | KEMET | KEMET |
| Product Status | Active | Active |
| Capacitance | 6.8 µF | 6.8 µF |
| Tolerance | ±10% | ±10% |
| Voltage Rating - AC | 310V | 310V |
| Voltage Rating - DC | 630V | - |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 5.8 mOhms | 3.3 mOhms |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 105°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial - 4 Leads | Radial - 4 Leads |
| Size / Dimension | 1.654" L x 0.787" W (42.00mm x 20.00mm) | 1.654" L x 0.787" W (42.00mm x 20.00mm) |
| Height - Seated (Max) | 1.583" (40.20mm) | 1.583" (40.20mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 1.476" (37.50mm) | 1.476" (37.50mm) |
| Applications | Automotive | Automotive |
| Ratings | AEC-Q200 | AEC-Q200 |
| Features | - | - |
