Please send RFQ , we will respond immediately.
| Part Number | C44AHGP5750ZA0J | C44AFGP5750ZA0J | C44AHGP5700ZA0J |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 75 µF | 75 µF | 70 µF |
| Tolerance | ±5% | ±5% | ±5% |
| Voltage Rating - AC | 330V | 250V | 330V |
| Voltage Rating - DC | 600V | 400V | 600V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 5 mOhms | 5 mOhms | 5 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Chassis, Stud Mount | Chassis, Stud Mount | Chassis, Stud Mount |
| Package / Case | Radial, Can | Radial, Can | Radial, Can |
| Size / Dimension | 2.559" Dia (65.00mm) | 2.362" Dia (60.00mm) | 2.559" Dia (65.00mm) |
| Height - Seated (Max) | 5.512" (140.00mm) | 4.055" (103.00mm) | 5.512" (140.00mm) |
| Termination | Threaded, Male | Threaded, Male | Threaded, Male |
| Lead Spacing | 0.878" (22.30mm) | 0.878" (22.30mm) | 0.878" (22.30mm) |
| Applications | General Purpose | General Purpose | General Purpose |
| Ratings | - | - | - |
| Features | - | - | - |
