Please send RFQ , we will respond immediately.
| Part Number | C440C103J5G5TA7200 | C440C153J5G5TA7200 | C440C103J1G5TA7200 | C440C103J5G5CA7200 |
|---|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active | Obsolete |
| Capacitance | 10000 pF | 0.015 µF | 10000 pF | 10000 pF |
| Tolerance | ±5% | ±5% | ±5% | ±5% |
| Voltage - Rated | 50V | 50V | 100V | 50V |
| Temperature Coefficient | C0G, NP0 | C0G, NP0 | C0G, NP0 | C0G, NP0 |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Features | Low ESL | Low ESL | Low ESL | Low ESL |
| Ratings | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.150" Dia x 0.400" L (3.81mm x 10.16mm) | 0.150" Dia x 0.400" L (3.81mm x 10.16mm) | 0.150" Dia x 0.400" L (3.81mm x 10.16mm) | 0.150" Dia x 0.400" L (3.81mm x 10.16mm) |
| Height - Seated (Max) | - | - | - | - |
| Thickness (Max) | - | - | - | - |
| Lead Spacing | - | - | - | - |
| Lead Style | Straight | Straight | Straight | Straight |
