| Part Number | C350C275K5R5TA | C350C475K5R5TA | C350C225K5R5TA |
|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active |
| Capacitance | 2.7 µF | 4.7 µF | 2.2 µF |
| Tolerance | ±10% | ±10% | ±10% |
| Voltage - Rated | 50V | 50V | 50V |
| Temperature Coefficient | X7R | X7R | X7R |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Features | - | - | - |
| Ratings | - | - | - |
| Applications | Bypass, Decoupling | General Purpose | General Purpose |
| Failure Rate | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial |
| Size / Dimension | 0.330" L x 0.200" W (8.38mm x 5.08mm) | 0.330" L x 0.200" W (8.38mm x 5.08mm) | 0.330" L x 0.200" W (8.38mm x 5.08mm) |
| Height - Seated (Max) | 0.400" (10.16mm) | 0.400" (10.16mm) | 0.400" (10.16mm) |
| Thickness (Max) | - | - | - |
| Lead Spacing | 0.400" (10.16mm) | 0.400" (10.16mm) | 0.400" (10.16mm) |
| Lead Style | Formed Leads | Formed Leads | Formed Leads |
