| Part Number | C340C105M1U5TA | C340C155M1U5TA | C340C105M5U5TA | C340C105M1U5CA |
|---|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active | Obsolete |
| Capacitance | 1 µF | 1.5 µF | 1 µF | 1 µF |
| Tolerance | ±20% | ±20% | ±20% | ±20% |
| Voltage - Rated | 100V | 100V | 50V | 100V |
| Temperature Coefficient | Z5U | Z5U | Z5U | Z5U |
| Operating Temperature | 10°C ~ 85°C | 10°C ~ 85°C | 10°C ~ 85°C | 10°C ~ 85°C |
| Features | - | - | - | - |
| Ratings | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial | Radial |
| Size / Dimension | 0.290" L x 0.160" W (7.36mm x 4.07mm) | 0.290" L x 0.160" W (7.36mm x 4.07mm) | 0.290" L x 0.160" W (7.36mm x 4.07mm) | 0.290" L x 0.160" W (7.36mm x 4.07mm) |
| Height - Seated (Max) | 0.400" (10.16mm) | 0.460" (11.68mm) | 0.500" (12.70mm) | 0.400" (10.16mm) |
| Thickness (Max) | - | - | - | - |
| Lead Spacing | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) | 0.200" (5.08mm) |
| Lead Style | Formed Leads | Straight | Straight | Formed Leads |
