KEMET-C317C220J2G5TA7301 - Ceramic Capacitors Product Specifications and Latest Quotes

Part Number	C317C220J2G5TA7301	C317C220K2G5TA7301	C317C220J3G5TA7301	C317C220JAG5TA7301	C317C222J2G5TA7301	C317C220J1G5TA7301
Manufacturer	KEMET	KEMET	KEMET	KEMET	KEMET	KEMET
Product Status	Active	Active	Active	Active	Active	Active
Capacitance	22 pF	22 pF	22 pF	22 pF	2200 pF	22 pF
Tolerance	±5%	±10%	±5%	±5%	±5%	±5%
Voltage - Rated	200V	200V	25V	250V	200V	100V
Temperature Coefficient	C0G, NP0	C0G, NP0	C0G, NP0	C0G, NP0	C0G, NP0	C0G, NP0
Operating Temperature	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C
Features	Low ESL	Low ESL	Low ESL	Low ESL	Low ESL	Low ESL
Ratings	-	-	-	-	-	-
Applications	General Purpose	General Purpose	General Purpose	General Purpose	General Purpose	General Purpose
Failure Rate	-	-	-	-	-	-
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Package / Case	Radial	Radial	Radial	Radial	Radial	Radial
Size / Dimension	0.150" L x 0.100" W (3.81mm x 2.54mm)	0.150" L x 0.100" W (3.81mm x 2.54mm)	0.150" L x 0.100" W (3.81mm x 2.54mm)	0.150" L x 0.100" W (3.81mm x 2.54mm)	0.150" L x 0.100" W (3.81mm x 2.54mm)	0.150" L x 0.100" W (3.81mm x 2.54mm)
Height - Seated (Max)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)
Thickness (Max)	-	-	-	-	-	-
Lead Spacing	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)	0.200" (5.08mm)
Lead Style	Formed Leads	Formed Leads	Formed Leads	Formed Leads	Formed Leads	Formed Leads

KEMET C317C220J2G5TA7301
