| Part Number | C1206X560M1HAC7800 | C1206X560M8HAC7800 | C1206X560M4HAC7800 | C1206X560M5HAC7800 | C1206X560M3HAC7800 | C1206X561M1HAC7800 | C1206X560F1HAC7800 | C1206X560G1HAC7800 | C1206X560J1HAC7800 | C1206X560K1HAC7800 |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | KEMET | KEMET | KEMET | KEMET | KEMET | KEMET | KEMET | KEMET | KEMET | KEMET |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Capacitance | 56 pF | 56 pF | 56 pF | 56 pF | 56 pF | 560 pF | 56 pF | 56 pF | 56 pF | 56 pF |
| Tolerance | ±20% | ±20% | ±20% | ±20% | ±20% | ±20% | ±1% | ±2% | ±5% | ±10% |
| Voltage - Rated | 100V | 10V | 16V | 50V | 25V | 100V | 100V | 100V | 100V | 100V |
| Temperature Coefficient | X8R | X8R | X8R | X8R | X8R | X8R | X8R | X8R | X8R | X8R |
| Operating Temperature | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C | -55°C ~ 150°C |
| Features | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature | Low ESL, Soft Termination, High Temperature |
| Ratings | - | - | - | - | - | - | - | - | - | - |
| Applications | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive | Boardflex Sensitive |
| Failure Rate | - | - | - | - | - | - | - | - | - | - |
| Mounting Type | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC | Surface Mount, MLCC |
| Package / Case | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) | 1206 (3216 Metric) |
| Size / Dimension | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) | 0.130" L x 0.063" W (3.30mm x 1.60mm) |
| Height - Seated (Max) | - | - | - | - | - | - | - | - | - | - |
| Thickness (Max) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) | 0.039" (0.98mm) |
| Lead Spacing | - | - | - | - | - | - | - | - | - | - |
| Lead Style | - | - | - | - | - | - | - | - | - | - |
