| Part Number | ALS40A473DF025 | ALS30A473DF025 |
|---|---|---|
| Manufacturer | KEMET | KEMET |
| Product Status | Active | Active |
| Capacitance | 47000 µF | 47000 µF |
| Tolerance | ±20% | ±20% |
| Voltage - Rated | 25 V | 25 V |
| ESR (Equivalent Series Resistance) | 9mOhm @ 100Hz | 9mOhm @ 100Hz |
| Lifetime @ Temp. | 6000 Hrs @ 105°C | 11000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 85°C |
| Polarization | Polar | Polar |
| Ratings | - | - |
| Applications | General Purpose | General Purpose |
| Ripple Current @ Low Frequency | 14 A @ 100 Hz | 16.6 A @ 100 Hz |
| Ripple Current @ High Frequency | 14.7 A @ 10 kHz | 17.4 A @ 10 kHz |
| Impedance | 8 mOhms | 7 mOhms |
| Lead Spacing | 0.504" (12.80mm) | 0.504" (12.80mm) |
| Size / Dimension | 1.417" Dia (36.00mm) | 1.417" Dia (36.00mm) |
| Height - Seated (Max) | 4.134" (105.00mm) | 4.134" (105.00mm) |
| Surface Mount Land Size | - | - |
| Mounting Type | Chassis Mount | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals | Radial, Can - Screw Terminals |
