KEMET-ALS36H103D3C050 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	10000 µF
Tolerance:	-10%, +30%
Voltage - Rated:	50 V
ESR (Equivalent Series Resistance):	24mOhm @ 120Hz
Lifetime @ Temp.:	11000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	11.7 A @ 120 Hz
Ripple Current @ High Frequency:	15.6 A @ 20 kHz
Impedance:	-
Lead Spacing:	0.500" (12.70mm)
Size / Dimension:	1.375" Dia (34.93mm)
Height - Seated (Max):	3.125" (79.38mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	Radial, Can - Screw Terminals

KEMET ALS36H103D3C050
