KEMET-ALS31A103MF100 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	10000 µF
Tolerance:	±20%
Voltage - Rated:	100 V
ESR (Equivalent Series Resistance):	28mOhm @ 100Hz
Lifetime @ Temp.:	-
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	10.1 A @ 100 Hz
Ripple Current @ High Frequency:	1.5 A @ 10 kHz
Impedance:	24 mOhms
Lead Spacing:	1.122" (28.50mm)
Size / Dimension:	2.598" Dia (66.00mm)
Height - Seated (Max):	4.134" (105.00mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	Radial, Can - Screw Terminals

KEMET ALS31A103MF100
