| Part Number | ALS31A103DA040 | ALS30A103DA040 |
|---|---|---|
| Manufacturer | KEMET | KEMET |
| Product Status | Active | Active |
| Capacitance | 10000 µF | 10000 µF |
| Tolerance | ±20% | ±20% |
| Voltage - Rated | 40 V | 40 V |
| ESR (Equivalent Series Resistance) | 23mOhm @ 100Hz | 23mOhm @ 100Hz |
| Lifetime @ Temp. | 11000 Hrs @ 85°C | 11000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Polarization | Polar | Polar |
| Ratings | - | - |
| Applications | General Purpose | General Purpose |
| Ripple Current @ Low Frequency | 7.9 A @ 100 Hz | 7.9 A @ 100 Hz |
| Ripple Current @ High Frequency | 8.4 A @ 10 kHz | 8.4 A @ 10 kHz |
| Impedance | 20 mOhms | 20 mOhms |
| Lead Spacing | 0.504" (12.80mm) | 0.504" (12.80mm) |
| Size / Dimension | 1.417" Dia (36.00mm) | 1.417" Dia (36.00mm) |
| Height - Seated (Max) | 2.047" (52.00mm) | 2.047" (52.00mm) |
| Surface Mount Land Size | - | - |
| Mounting Type | Chassis Mount | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals | Radial, Can - Screw Terminals |
