KEMET-ALS30A153DA025 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	15000 µF
Tolerance:	±20%
Voltage - Rated:	25 V
ESR (Equivalent Series Resistance):	24mOhm @ 100Hz
Lifetime @ Temp.:	11000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	8.2 A @ 100 Hz
Ripple Current @ High Frequency:	8.7 A @ 10 kHz
Impedance:	20 mOhms
Lead Spacing:	0.504" (12.80mm)
Size / Dimension:	1.417" Dia (36.00mm)
Height - Seated (Max):	2.047" (52.00mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	Radial, Can - Screw Terminals

KEMET ALS30A153DA025
