KEMET-ALF70G303KP100 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	30000 µF
Tolerance:	±20%
Voltage - Rated:	100 V
ESR (Equivalent Series Resistance):	14mOhm @ 100Hz
Lifetime @ Temp.:	18000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	16.07 A @ 100 Hz
Ripple Current @ High Frequency:	18.16 A @ 10 kHz
Impedance:	12 mOhms
Lead Spacing:	0.984" (25.00mm)
Size / Dimension:	1.969" Dia (50.00mm)
Height - Seated (Max):	4.213" (107.00mm)
Surface Mount Land Size:	-
Mounting Type:	Through Hole, Press-Fit
Package / Case:	Radial, Can - Press-Fit - 5 Lead

KEMET ALF70G303KP100
