KEMET-ALF70G162EL400 - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	1600 µF
Tolerance:	±20%
Voltage - Rated:	400 V
ESR (Equivalent Series Resistance):	92mOhm @ 100Hz
Lifetime @ Temp.:	18000 Hrs @ 85°C
Operating Temperature:	-40°C ~ 85°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	5.27 A @ 100 Hz
Ripple Current @ High Frequency:	10.65 A @ 10 kHz
Impedance:	51 mOhms
Lead Spacing:	0.984" (25.00mm)
Size / Dimension:	1.575" Dia (40.00mm)
Height - Seated (Max):	3.228" (82.00mm)
Surface Mount Land Size:	-
Mounting Type:	Through Hole, Press-Fit
Package / Case:	Radial, Can - Press-Fit - 5 Lead

KEMET ALF70G162EL400
