KEMET-A958AL112M800S - Aluminum Electrolytic Capacitors Product Specifications and Latest Quotes

Capacitance:	1100 µF
Tolerance:	±20%
Voltage - Rated:	800 V
ESR (Equivalent Series Resistance):	125mOhm @ 100Hz
Lifetime @ Temp.:	9000 Hrs @ 105°C
Operating Temperature:	-40°C ~ 105°C
Polarization:	Polar
Ratings:	-
Applications:	General Purpose
Ripple Current @ Low Frequency:	11.6 A @ 100 Hz
Ripple Current @ High Frequency:	26.4 A @ 10 kHz
Impedance:	74 mOhms
Lead Spacing:	-
Size / Dimension:	5.567" L x 4.331" W (141.40mm x 110.00mm)
Height - Seated (Max):	3.803" (96.60mm)
Surface Mount Land Size:	-
Mounting Type:	Chassis Mount
Package / Case:	-

KEMET A958AL112M800S
