KEMET-4ATHBW4330A3GJ - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	3.3 µF
Tolerance:	±5%
Voltage Rating - AC:	350V
Voltage Rating - DC:	600V
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	2.4 mOhms
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Through Hole
Package / Case:	Radial - 4 Leads
Size / Dimension:	1.260" L x 0.866" W (32.00mm x 22.00mm)
Height - Seated (Max):	1.457" (37.00mm)
Termination:	PC Pins
Lead Spacing:	1.083" (27.50mm)
Applications:	DC Link, DC Filtering; High Frequency, Switching
Ratings:	-
Features:	-

KEMET 4ATHBW4330A3GJ
