KEMET-274AC35200SA0J - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	20 µF
Tolerance:	±5%
Voltage Rating - AC:	470V
Voltage Rating - DC:	-
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	-
Operating Temperature:	-25°C ~ 85°C
Mounting Type:	Chassis, Stud Mount
Package / Case:	Radial, Can
Size / Dimension:	1.772" Dia (45.00mm)
Height - Seated (Max):	2.992" (76.00mm)
Termination:	Quick Connect - 0.250" (6.3mm)
Lead Spacing:	0.528" (13.40mm)
Applications:	Motor Run; Motor Start
Ratings:	-
Features:	-

KEMET 274AC35200SA0J
