IXYS-VUM25-05E - Diodes - Bridge Rectifiers Product Specifications and Latest Quotes

Diode Type:	Three Phase (PFC Module)
Technology:	Standard
Voltage - Peak Reverse (Max):	600 V
Current - Average Rectified (Io):	40 A
Voltage - Forward (Vf) (Max) @ If:	1.65 V @ 22 A
Current - Reverse Leakage @ Vr:	1.5 mA @ 600 V
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Chassis Mount
Package / Case:	V1A-PAK
Supplier Device Package:	V1A-PAK

IXYS VUM25-05E
