Please send RFQ , we will respond immediately.
| Part Number | VBO13-12AO2 | VBO13-16AO2 | VBO13-12NO2 | VBO13-14AO2 |
|---|---|---|---|---|
| Manufacturer | IXYS | IXYS | IXYS | IXYS |
| Product Status | Obsolete | Obsolete | Obsolete | Active |
| Diode Type | Single Phase | Single Phase | Single Phase | Single Phase |
| Technology | Avalanche | Avalanche | Standard | Avalanche |
| Voltage - Peak Reverse (Max) | 1.2 kV | 1.6 kV | 1.2 kV | 1.4 kV |
| Current - Average Rectified (Io) | 18 A | 18 A | 18 A | 18 A |
| Voltage - Forward (Vf) (Max) @ If | 1.8 V @ 55 A | 1.8 V @ 55 A | 1.8 V @ 55 A | 1.8 V @ 55 A |
| Current - Reverse Leakage @ Vr | 300 µA @ 1200 V | 300 µA @ 1600 V | 300 µA @ 1200 V | 300 µA @ 1400 V |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | QC Terminal | QC Terminal | QC Terminal | QC Terminal |
| Package / Case | 4-Square, FO-A | 4-Square, FO-A | 4-Square, FO-A | 4-Square, FO-A |
| Supplier Device Package | FO-A | FO-A | FO-A | FO-A |
