| Part Number | MDO500-22N1 | MDO500-12N1 |
|---|---|---|
| Manufacturer | IXYS | IXYS |
| Product Status | Active | Active |
| Diode Type | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 2200 V | 1200 V |
| Current - Average Rectified (Io) | 560A | 560A |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 1200 A | 1.3 V @ 1200 A |
| Speed | Standard Recovery >500ns, > 200mA (Io) | Standard Recovery >500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | - |
| Current - Reverse Leakage @ Vr | 30 mA @ 2200 V | 30 mA @ 1200 V |
| Capacitance @ Vr, F | 576pF @ 700V, 1MHz | 762pF @ 400V, 1MHz |
| Mounting Type | Chassis Mount | Chassis Mount |
| Package / Case | Y1-CU | Y1-CU |
| Supplier Device Package | Y1-CU | Y1-CU |
| Operating Temperature - Junction | - | - |
