Please send RFQ , we will respond immediately.
| Part Number | IXTV102N25T | IXTV102N20T |
|---|---|---|
| Manufacturer | IXYS | IXYS |
| Product Status | Active | Obsolete |
| FET Type | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 250 V | 200 V |
| Current - Continuous Drain (Id) @ 25°C | 102A (Tc) | 102A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 10V |
| Rds On (Max) @ Id, Vgs | - | 23mOhm @ 500mA, 10V |
| Vgs(th) (Max) @ Id | - | 4.5V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | - | 114 nC @ 10 V |
| Vgs (Max) | - | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 6800 pF @ 25 V |
| FET Feature | - | - |
| Power Dissipation (Max) | - | 750W (Tc) |
| Operating Temperature | - | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole |
| Supplier Device Package | PLUS220 | PLUS220 |
| Package / Case | TO-220-3, Short Tab | TO-220-3, Short Tab |
