| Part Number | IXTV102N20T | IXTV102N25T |
|---|---|---|
| Manufacturer | IXYS | IXYS |
| Product Status | Obsolete | Active |
| FET Type | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 200 V | 250 V |
| Current - Continuous Drain (Id) @ 25°C | 102A (Tc) | 102A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | - |
| Rds On (Max) @ Id, Vgs | 23mOhm @ 500mA, 10V | - |
| Vgs(th) (Max) @ Id | 4.5V @ 1mA | - |
| Gate Charge (Qg) (Max) @ Vgs | 114 nC @ 10 V | - |
| Vgs (Max) | ±30V | - |
| Input Capacitance (Ciss) (Max) @ Vds | 6800 pF @ 25 V | - |
| FET Feature | - | - |
| Power Dissipation (Max) | 750W (Tc) | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | - |
| Mounting Type | Through Hole | Through Hole |
| Supplier Device Package | PLUS220 | PLUS220 |
| Package / Case | TO-220-3, Short Tab | TO-220-3, Short Tab |
