Please send RFQ , we will respond immediately.
| Part Number | IXTC180N10T | IXTH180N10T | IXTC160N10T |
|---|---|---|---|
| Manufacturer | IXYS | IXYS | IXYS |
| Product Status | Obsolete | Active | Obsolete |
| FET Type | N-Channel | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100 V | 100 V | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 90A (Tc) | 180A (Tc) | 83A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 10V | 10V |
| Rds On (Max) @ Id, Vgs | - | 6.4mOhm @ 25A, 10V | 7.5mOhm @ 25A, 10V |
| Vgs(th) (Max) @ Id | - | 4.5V @ 250µA | 4.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | - | 151 nC @ 10 V | 132 nC @ 10 V |
| Vgs (Max) | - | ±30V | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 6900 pF @ 25 V | 6600 pF @ 25 V |
| FET Feature | - | - | - |
| Power Dissipation (Max) | 150W (Tc) | 480W (Tc) | 140W (Tc) |
| Operating Temperature | - | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Supplier Device Package | ISOPLUS220™ | TO-247 (IXTH) | ISOPLUS220™ |
| Package / Case | ISOPLUS220™ | TO-247-3 | ISOPLUS220™ |
