IXYS-DSI75-12B - Diodes - Rectifiers - Single Product Specifications and Latest Quotes

Diode Type:	Standard
Voltage - DC Reverse (Vr) (Max):	1200 V
Current - Average Rectified (Io):	110A
Voltage - Forward (Vf) (Max) @ If:	1.17 V @ 150 A
Speed:	Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr):	-
Current - Reverse Leakage @ Vr:	6 mA @ 1200 V
Capacitance @ Vr, F:	-
Mounting Type:	Chassis, Stud Mount
Package / Case:	DO-203AB, DO-5, Stud
Supplier Device Package:	DO-203AB
Operating Temperature - Junction:	-40°C ~ 180°C

IXYS DSI75-12B
