IXYS Integrated Circuits Division-CPC1596G - Isolators - Gate Drivers Product Specifications and Latest Quotes

Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	-
Propagation Delay tpLH / tpHL (Max):	-
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	-
Current - Output High, Low:	1A, 1A
Current - Peak Output:	1A
Voltage - Forward (Vf) (Typ):	1.4V
Current - DC Forward (If) (Max):	10 mA
Voltage - Output Supply:	15V ~ 570V
Operating Temperature:	-40°C ~ 110°C
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-DIP
Approval Agency:	CSA, UL

IXYS Integrated Circuits Division CPC1596G
