CPC1301GR Image
×
Favorite
Compare
Add to RFQ
Share:
IXYS Integrated Circuits Division CPC1301GR
Manufacturer No:
CPC1301GR
Manufacturer:
IXYS Integrated Circuits Division
Package:
Tube
Datasheet:
CPC1301GR Datasheet
ECAD Model:
-
Description:
OPTOISOLTR 5KV DARLINGTON 4-SMD
Delivery:
Payment:
Product Attributes
Number of Channels:
1
Voltage - Isolation:
5000Vrms
Current Transfer Ratio (Min):
1000% @ 1mA
Current Transfer Ratio (Max):
8000% @ 1mA
Turn On / Turn Off Time (Typ):
1µs, 80µs
Rise / Fall Time (Typ):
40µs, 2.6µs
Input Type:
DC
Output Type:
Darlington
Voltage - Output (Max):
350V
Current - Output / Channel:
-
Voltage - Forward (Vf) (Typ):
1.2V
Current - DC Forward (If) (Max):
1 mA
Vce Saturation (Max):
1.2V
Operating Temperature:
-40°C ~ 85°C
Mounting Type:
Surface Mount
Package / Case:
4-SMD, Gull Wing
Supplier Device Package:
4-SMD
0
Remaining
View Similar
In Stock
UnitPrice:
$2.15
Quantity:
7
