| Part Number | XMC4500F100K1024AAXQSA1 | XMC4500F100K1024ACXQSA1 | XMC4500F100K1024ABXQSA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active | Obsolete |
| Core Processor | - | ARM® Cortex®-M4 | ARM® Cortex®-M4 |
| Core Size | - | 32-Bit Single-Core | 32-Bit Single-Core |
| Speed | - | 120MHz | 120MHz |
| Connectivity | - | CANbus, EBI/EMI, Ethernet, I²C, LINbus, SPI, UART, USB | CANbus, EBI/EMI, Ethernet, I²C, LINbus, SPI, UART, USB |
| Peripherals | - | DMA, I²S, LED, POR, PWM, WDT | DMA, I²S, LED, POR, PWM, WDT |
| Number of I/O | - | 55 | 55 |
| Program Memory Size | - | 1MB (1M x 8) | 1MB (1M x 8) |
| Program Memory Type | - | Flash | Flash |
| EEPROM Size | - | - | - |
| RAM Size | - | 160K x 8 | 160K x 8 |
| Voltage - Supply (Vcc/Vdd) | - | 3.13V ~ 3.63V | 3.13V ~ 3.63V |
| Data Converters | - | A/D 24x12b; D/A 2x12b | A/D 24x12b; D/A 2x12b |
| Oscillator Type | - | Internal | Internal |
| Operating Temperature | - | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | - | Surface Mount | Surface Mount |
| Package / Case | - | 100-LQFP Exposed Pad | 100-LQFP Exposed Pad |
| Supplier Device Package | - | PG-LQFP-100-11 | PG-LQFP-100-11 |
