| Part Number | TLS850F1TAV50ATMA1 | TLS850F2TAV50ATMA1 | TLS850F0TAV50ATMA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active | Active |
| Output Configuration | Positive | Positive | Positive |
| Output Type | Fixed | Fixed | Fixed |
| Number of Regulators | 1 | 1 | 1 |
| Voltage - Input (Max) | 40V | 40V | 40V |
| Voltage - Output (Min/Fixed) | 5V | 5V | 5V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | 0.425V @ 250mA | 0.175V @ 250mA | 0.425V @ 250mA |
| Current - Output | 500mA | 500mA | 500mA |
| Current - Quiescent (Iq) | 5 µA | 80 µA | 5 µA |
| Current - Supply (Max) | 82 µA | 82 µA | 82 µA |
| PSRR | 59dB (100Hz) | 59dB (100Hz) | 59dB (100Hz) |
| Control Features | Enable, Reset, Watchdog | Enable, Power Fail | Enable, Reset, Watchdog |
| Protection Features | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | TO-263-8, D²Pak (7 Leads + Tab), TO-263CA | TO-263-8, D²Pak (7 Leads + Tab), TO-263CA | TO-263-8, D²Pak (7 Leads + Tab), TO-263CA |
| Supplier Device Package | PG-TO263-7-1 | PG-TO263-7-1 | PG-TO263-7-1 |
