| Part Number | TLS810B1LDV33XUMA1 | TLS810D1LDV33XUMA1 | TLS810A1LDV33XUMA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active | Active |
| Output Configuration | Positive | Positive | Positive |
| Output Type | Fixed | Fixed | Fixed |
| Number of Regulators | 1 | 1 | 1 |
| Voltage - Input (Max) | 42V | 42V | 42V |
| Voltage - Output (Min/Fixed) | 3.3V | 3.3V | 3.3V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | 0.65V @ 100mA | 0.65V @ 100mA | 0.65V @ 100mA |
| Current - Output | 100mA | 100mA | 100mA |
| Current - Quiescent (Iq) | 10 µA | 10 µA | 10 µA |
| Current - Supply (Max) | 15 µA | 15 µA | 15 µA |
| PSRR | 60dB (100Hz) | 60dB (100Hz) | 60dB (100Hz) |
| Control Features | Enable | Enable | - |
| Protection Features | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount, Wettable Flank | Surface Mount, Wettable Flank |
| Package / Case | 10-TFDFN Exposed Pad | 10-TFDFN Exposed Pad | 10-TFDFN Exposed Pad |
| Supplier Device Package | PG-TSON-10 | PG-TSON-10-2 | PG-TSON-10-2 |
