Please send RFQ , we will respond immediately.
| Part Number | TLE4279G | TLE4299G | TLE4275G | TLE4278G |
|---|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Active | Active | Active | Active |
| Output Configuration | - | Positive | Positive | Positive |
| Output Type | - | Fixed | Fixed | Fixed |
| Number of Regulators | - | 1 | 1 | 1 |
| Voltage - Input (Max) | - | 45V | 42V | 45V |
| Voltage - Output (Min/Fixed) | - | 5V | 5V | 5V |
| Voltage - Output (Max) | - | - | - | - |
| Voltage Dropout (Max) | - | 0.5V @ 100mA | 0.5V @ 300mA | 0.5V @ 150mA |
| Current - Output | - | 150mA | 450mA | 200mA |
| Current - Quiescent (Iq) | - | 105 µA | 220 µA | 200 µA |
| Current - Supply (Max) | - | - | 22 mA | 12 mA |
| PSRR | - | 66dB (100Hz) | 60dB (100Hz) | - |
| Control Features | - | Reset | Reset | Reset, Watchdog |
| Protection Features | - | Over Current, Over Temperature, Reverse Polarity, Short Circuit | Antisaturation, Over Current, Over Temperature, Reverse Polarity, Short Circuit | Over Temperature, Reverse Polarity, Short Circuit |
| Operating Temperature | - | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | - | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | - | 8-SOIC (0.154", 3.90mm Width) | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | - | PG-DSO-8-1 | PG-TO263-5-1 | PG-DSO-14 |
