| Part Number | TLE4250GHTSA1 | TLE4250GNTSA1 | TLE42502GHTSA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Last Time Buy | Not For New Designs | Active |
| Output Configuration | Positive | Positive | Positive |
| Output Type | Adjustable | Adjustable | Adjustable |
| Number of Regulators | 1 | 1 | 1 |
| Voltage - Input (Max) | 40V | 40V | 40V |
| Voltage - Output (Min/Fixed) | Tracking | Tracking | Tracking |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | 0.3V @ 10mA | 0.3V @ 10mA | 0.3V @ 10mA |
| Current - Output | 50mA | 50mA | 50mA |
| Current - Quiescent (Iq) | 20 µA | 20 µA | 20 µA |
| Current - Supply (Max) | 3 mA | 3 mA | 5 mA |
| PSRR | 60dB (100Hz) | 60dB (100Hz) | 48dB (100Hz) |
| Control Features | Enable | Enable | Enable |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Short Circuit | Over Current, Over Temperature, Reverse Polarity, Short Circuit | Over Current, Over Temperature, Reverse Polarity, Short Circuit |
| Operating Temperature | -40°C ~ 150°C | -40°C ~ 150°C | -40°C ~ 150°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-SMD (5 Leads), Gull Wing | 6-SMD (5 Leads), Gull Wing | 6-SMD (5 Leads), Gull Wing |
| Supplier Device Package | PG-SCT595-5-1 | PG-SCT595-5-1 | PG-SCT595-5-1 |
