| Part Number | MB91F527YWCPB-GSK5E1 | MB91F528YWCPB-GSK5E1 |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Obsolete | Active |
| Core Processor | FR81S | FR81S |
| Core Size | 32-Bit Single-Core | 32-Bit Single-Core |
| Speed | 128MHz | 128MHz |
| Connectivity | CANbus, CSIO, EBI/EMI, I²C, LINbus, SPI, UART/USART | CANbus, CSIO, EBI/EMI, I²C, LINbus, SPI, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT | DMA, LVD, POR, PWM, WDT |
| Number of I/O | 219 | 219 |
| Program Memory Size | 1.5625MB (1.5625M x 8) | 2.0625MB (2.0625M x 8) |
| Program Memory Type | Flash | Flash |
| EEPROM Size | 64K x 8 | 64K x 8 |
| RAM Size | 208K x 8 | 336K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V | 2.7V ~ 5.5V |
| Data Converters | A/D 64x12b; D/A 2x8b | A/D 64x12b; D/A 2x8b |
| Oscillator Type | External | External |
| Operating Temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 416-BGA | 416-BGA |
| Supplier Device Package | 416-PBGA (27x27) | 416-PBGA (27x27) |
