| Part Number | IFX1963TBVATMA1 | IFX1963TEVATMA1 |
|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies |
| Product Status | Obsolete | Last Time Buy |
| Output Configuration | Positive | Positive |
| Output Type | Adjustable | Adjustable |
| Number of Regulators | 1 | 1 |
| Voltage - Input (Max) | 20V | 20V |
| Voltage - Output (Min/Fixed) | 1.21V | 1.21V |
| Voltage - Output (Max) | 19.45V | 19.45V |
| Voltage Dropout (Max) | 0.55V @ 1.5A | 0.55V @ 1.5A |
| Current - Output | 1.5A | 1.5A |
| Current - Quiescent (Iq) | 1.5 mA | 1.5 mA |
| Current - Supply (Max) | 130 mA | 130 mA |
| PSRR | 67dB (120Hz) | 67dB (120Hz) |
| Control Features | Enable | Enable |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Short Circuit | Over Current, Over Temperature, Reverse Polarity, Short Circuit |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
| Supplier Device Package | PG-TO263-5-1 | PG-TO252-5-13 |
