Please send RFQ , we will respond immediately.
| Part Number | FS100R06KE3BOSA1 | FS150R06KE3BOSA1 | FS200R06KE3BOSA1 |
|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Not For New Designs | Active | Active |
| IGBT Type | Trench Field Stop | Trench Field Stop | Trench Field Stop |
| Configuration | Three Phase Inverter | Three Phase Inverter | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 600 V | 600 V | 600 V |
| Current - Collector (Ic) (Max) | 100 A | 150 A | 200 A |
| Power - Max | 335 W | 430 W | 600 W |
| Vce(on) (Max) @ Vge, Ic | 1.9V @ 15V, 100A | 1.9V @ 15V, 150A | 1.9V @ 15V, 200A |
| Current - Collector Cutoff (Max) | 1 mA | 1 mA | 1 mA |
| Input Capacitance (Cies) @ Vce | 6.2 nF @ 25 V | 9.3 nF @ 25 V | 13 nF @ 25 V |
| Input | Standard | Standard | Standard |
| NTC Thermistor | Yes | No | Yes |
| Operating Temperature | -40°C ~ 150°C | -40°C ~ 150°C (TJ) | -40°C ~ 150°C |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount |
| Package / Case | Module | Module | Module |
| Supplier Device Package | Module | Module | Module |
