| Part Number | FF600R12ME4EB11BOSA1 | FF600R12ME4PB11BOSA1 | FF600R12ME4AB11BOSA1 | FF600R12ME4CB11BOSA1 |
|---|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Discontinued at Digi-Key | Not For New Designs | Discontinued at Digi-Key | Discontinued at Digi-Key |
| IGBT Type | Trench Field Stop | - | Trench Field Stop | Trench Field Stop |
| Configuration | Half Bridge | - | 2 Independent | 2 Independent |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V | - | 1200 V | 1200 V |
| Current - Collector (Ic) (Max) | 995 A | - | - | 1060 A |
| Power - Max | 4050 W | - | 3350 W | 4050 W |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 600A | - | 2.1V @ 15V, 600A | 2.1V @ 15V, 600A |
| Current - Collector Cutoff (Max) | 3 mA | - | 3 mA | 3 mA |
| Input Capacitance (Cies) @ Vce | 37 nF @ 25 V | - | 37 nF @ 25 V | 37 nF @ 25 V |
| Input | Standard | - | Standard | Standard |
| NTC Thermistor | Yes | - | Yes | Yes |
| Operating Temperature | -40°C ~ 150°C | - | -40°C ~ 150°C | -40°C ~ 150°C |
| Mounting Type | Chassis Mount | - | Chassis Mount | Chassis Mount |
| Package / Case | Module | - | Module | Module |
| Supplier Device Package | Module | - | Module | Module |
