Please send RFQ , we will respond immediately.
| Part Number | FF2MR12KM1PHOSA1 | FF3MR12KM1PHOSA1 | FF6MR12KM1PHOSA1 | FF2MR12KM1HOSA1 |
|---|---|---|---|---|
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Product Status | Last Time Buy | Last Time Buy | Last Time Buy | Last Time Buy |
| FET Type | 2 N-Channel (Half Bridge) | 2 N-Channel (Half Bridge) | 2 N-Channel (Half Bridge) | 2 N-Channel (Half Bridge) |
| FET Feature | Standard | Standard | Silicon Carbide (SiC) | Standard |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) | 1200V (1.2kV) | 1200V (1.2kV) | 1200V (1.2kV) |
| Current - Continuous Drain (Id) @ 25°C | 500A (Tc) | 375A (Tc) | 250A (Tc) | 500A (Tc) |
| Rds On (Max) @ Id, Vgs | 2.13mOhm @ 500A, 15V | 2.83mOhm @ 375A, 15V | 5.81mOhm @ 250A, 15V | 2.13mOhm @ 500A, 15V |
| Vgs(th) (Max) @ Id | 5.15V @ 224mA | 5.15V @ 168mA | 5.15V @ 80mA | 5.15V @ 224mA |
| Gate Charge (Qg) (Max) @ Vgs | 1340nC @ 15V | 1000nC @ 15V | 496nC @ 15V | 1340nC @ 15V |
| Input Capacitance (Ciss) (Max) @ Vds | 39700pF @ 800V | 29800pF @ 25V | 14700pF @ 800V | 39700pF @ 800V |
| Power - Max | - | - | - | - |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount |
| Package / Case | Module | Module | Module | Module |
| Supplier Device Package | AG-62MM | AG-62MM | AG-62MM | AG-62MM |
